The all NEW release from Penn fishing with their flagship Authority Spinning reel. With an IPX8 sealed body AND spool, this reel takes long runs in heavy seas or the pounding of big surf in its stride. Beefed up by ultra-durable CNC machined stainless steel main and pinion gears, the patented Dura-Drag™ technology enforces obedience, eliminating hesitation even under the most extreme settings. A 12+1 premium stainless steel bearing system combines with Leveline slow oscillation to ensure enduring smoothness and precision, behind all that trademark PENN® power. The lasting AUTHORITY™ in saltwater spinning reels is here.
| MODEL | BRAID CAPACITY YD/LB | MONO CAPACITY YD/LB | GEAR RATIO | RECOVERY RATE | MAX DRAG | BEARING COUNT | WEIGHT |
|---|---|---|---|---|---|---|---|
| ATH2500 | 240/10 220/15 160/20 | 255/6 175/8 140/10 | 5.7:1 | 30in | 76cm | 20lb | 9.1kg | 12+1 | 337g |
| ATH2500HS | 240/10 220/15 160/20 | 255/6 175/8 140/10 | 7.0:1 | 37in | 94cm | 20lb | 9.1kg | 12+1 | 337g |
| ATH3500 | 310/10 270/15 220/20 | 360/6 285/8 220/10 | 5.7:1 | 34in | 86.5cm | 30lb | 13.6kg | 12+1 | 405g |
| ATH4500 | 390/15 320/20 250/30 | 425/8 320/10 235/12 | 5.7:1 | 37in | 94cm | 30lb | 13.6kg | 12+1 | 425g |
| ATH4500HS | 390/15 320/20 250/30 | 425/8 320/10 235/12 | 7.0:1 | 45in | 114cm | 30lb | 13.6kg | 12+1 | 425g |
| ATH5500 | 500/20 380/30 335/40 | 430/10 330/12 230/15 | 5.2:1 | 36in | 91.5cm | 40lb | 18.1kg | 12+1 | 669g |
| ATH6500 | 485/30 410/40 335/50 | 390/12 345/15 205/20 | 5.2:1 | 39in | 99cm | 40lb | 18.1kg | 12+1 | 720g |
| ATH6500HS | 485/30 410/40 335/50 | 390/12 345/15 205/20 | 6.2:1 | 48in | 122cm | 40lb | 18.1kg | 12+1 | 720g |
| ATH7500 | 530/40 440/50 400/65 | 490/15 330/20 220/30 | 4.7:1 | 38in | 96.5cm | 50lb | 22.7kg | 12+1 | 842g |
| ATH8500 | 730/40 600/50 555/65 | 455/20 310/30 260/40 | 4.7:1 | 42in | 107cm | 50lb | 22.7kg | 12+1 | 882g |
| ATH8500HS | 730/40 600/50 555/65 | 455/20 310/30 260/40 | 5.3:1 | 50in | 127cm | 50lb | 22.7kg | 12+1 | 882g |
| ATH10500 | 845/50 780/65 540/80 | 435/30 360/40 255/50 | 4.2:1 | 43in | 109cm | 60lb | 27.2kg | 12+1 |
| Size | 10500, 3500, 4500, 5500, 6500, 7500, 8500, 8500HS |
|---|
